What is a Proxy? Forward Proxy, Reverse Proxy and SOCKS5 Explained

Proxy is one of those networking concepts that appears everywhere yet is often misunderstood. Forward proxy, reverse proxy, SOCKS5 — each type serves a different purpose. This article clearly explains each one with real-world configuration examples.

What is a Proxy?

A proxy server is an intermediary server that acts on behalf of either a client or a server during network communication. Instead of the client connecting directly to the destination server, all traffic passes through the proxy.

Benefits of using a proxy:

• Anonymity: Hides the real IP address of the client or server
• Caching: Stores responses to serve repeated requests faster (without fetching from the origin)
• Access control: Blocks or allows traffic based on policy
• Load balancing: Distributes traffic across multiple backend servers
• SSL termination: Handles TLS at the proxy level so backends can use plain HTTP

There are three main types of proxy: Forward Proxy, Reverse Proxy, and SOCKS5 Proxy.

Forward Proxy

A Forward Proxy sits between the client and the internet. The client knows it is using a proxy and must configure it explicitly (in the browser, OS, or application).

Traffic flow:

Client → Forward Proxy → Internet → Destination Server

The destination server sees the proxy's IP, not the client's real IP.

Common use cases:

• Corporate web filtering: IT departments block inappropriate websites (social media, games) and log web access
• Bypassing geo-restrictions: A client in Vietnam uses a US-based proxy to access content restricted to the US
• Development and debugging: Dev teams use proxies to intercept and inspect HTTP requests (Charles Proxy, mitmproxy)

Squid Forward Proxy — basic configuration:

 1# Install Squid
 2apt-get install squid
 3
 4# /etc/squid/squid.conf
 5http_port 3128
 6
 7# Allow internal network
 8acl localnet src 192.168.0.0/16
 9acl localnet src 10.0.0.0/8
10http_access allow localnet
11
12# Block social media
13acl social dstdomain .facebook.com .tiktok.com .youtube.com
14http_access deny social
15
16# Deny all other traffic
17http_access deny all

1# Test the proxy from a client
2curl -x http://proxy-server:3128 https://httpbin.org/ip
3# The response will return the proxy's IP, not the client's
4
5# Set proxy for the entire terminal session
6export http_proxy="http://proxy-server:3128"
7export https_proxy="http://proxy-server:3128"

Reverse Proxy

A Reverse Proxy sits in front of backend servers. The client (browser) does not know the proxy exists — they think they are connecting directly to the real server. The backend IP addresses are completely hidden from the client.

Traffic flow:

Client → Reverse Proxy → Backend Server 1
                       → Backend Server 2
                       → Backend Server 3

NGINX as a Reverse Proxy:

 1# /etc/nginx/sites-available/myapp
 2server {
 3    listen 80;
 4    server_name api.example.com;
 5
 6    location / {
 7        proxy_pass http://localhost:3000;
 8        proxy_set_header Host $host;
 9        proxy_set_header X-Real-IP $remote_addr;
10        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
11        proxy_set_header X-Forwarded-Proto $scheme;
12    }
13}
14
15# Load balancing with upstream
16upstream backend_pool {
17    server 10.0.1.10:3000 weight=3;
18    server 10.0.1.11:3000 weight=1;
19    server 10.0.1.12:3000 backup;
20}
21
22server {
23    listen 443 ssl;
24    server_name api.example.com;
25
26    location /api/ {
27        proxy_pass http://backend_pool;
28    }
29}

Common use cases for a Reverse Proxy:

• SSL termination: NGINX handles TLS; backends only need plain HTTP
• Load balancing: Distributes requests across multiple instances
• Static file serving: NGINX serves static assets; backends focus on business logic
• Rate limiting: Limits requests from a single IP address
• Security: Hides backend information (versions, IPs, ports)

SOCKS5 Proxy

SOCKS5 is a proxy that operates at the session layer (OSI Layer 5) and is independent of the application protocol. It tunnels any TCP/UDP traffic — HTTP, SMTP, FTP, SSH, game traffic, and more.

Creating a SOCKS5 proxy via SSH tunnel:

 1# Create an SSH SOCKS5 tunnel (port 1080 on localhost)
 2ssh -D 1080 -N -f user@jumphost.example.com
 3# -D 1080: create a SOCKS5 proxy on port 1080
 4# -N: do not execute a remote command
 5# -f: run in the background
 6
 7# Test via SOCKS5
 8curl --socks5 127.0.0.1:1080 https://httpbin.org/ip
 9curl --socks5-hostname 127.0.0.1:1080 https://ifconfig.me
10
11# Use with git (proxy git pull through the SSH tunnel)
12git config --global http.proxy socks5://127.0.0.1:1080

Configuring SOCKS5 in Python (requests library):

1import requests
2
3proxies = {
4    "http": "socks5://127.0.0.1:1080",
5    "https": "socks5://127.0.0.1:1080",
6}
7
8response = requests.get("https://httpbin.org/ip", proxies=proxies)
9print(response.json())  # Returns the proxy's IP, not the real IP

SOCKS5 vs HTTP Proxy:

Proxy vs VPN

Both proxies and VPNs hide your real IP and route traffic through an intermediary server, but they differ significantly in how they work:
